Scope · sampleCedar privacy, 6 ftNot a quote until signed
Run: 142 lf, 3 sides, 1 walk gate
Linear feet measured on the ground with a wheel and checked with a tape at every corner. Not off a satellite photo, which misses a 6 ft jog around a tree every time.
Line posts: 19 × 2-3/8 in galv. steel, 8 ft o.c., 24 in deep
Each post position is numbered and drawn on the sketch. 8 ft spacing matches 8 ft cedar rails, so there is no rail splice floating between posts.
Gate posts: 2 × 4 in square steel, 36 in deep
The extra foot is what keeps a gate latching in year five. We don't hang a gate over 4 ft on wood. Ever.
Concrete: 2 bags per line post, 4 per gate post = 46 bags
You can count the bags on the pallet when it arrives. If we use more because a hole broke into a void, the scope says what happens, and it doesn't come as a surprise on the invoice.
Rails: 2x4 western red cedar, 3 rows
Three rows on a 6 ft run, not two. Two rails let the middle of the pickets bow outward after one summer.
Pickets: 1x6 WRC, board on board, 1-1/2 in overlap
Cedar shrinks across its width. The overlap means you still don't see through the fence when it does. Species is written so nobody substitutes treated pine and calls it cedar.
Gate: 48 in steel frame, cedar clad, adjustable hinges, gravity latch
The finished opening, the hinge type and the latch side are all written. Tell us now if the latch needs to be reachable from both sides.
Tear-out & haul: 128 lf existing wood, footings removed
Old concrete footings come out. Leaving them means the new post goes beside the old hole in softer ground.
Start: written date · Duration: 3 working days
A date, not a week. Rain over half an inch moves it, and you get the new date in writing the same day.
